Gadolinium Scandium Gallium Garnet (GSGG) Single Crystal Wafers

Gadolinium Scandium Gallium Garnet GSGG (Gd3Sc2Ga5O12) Single Crystal Wafers

Physical Properties:
– Crystal Structure: Cubic System
– Lattice Constant: a=12.554 Angstrom
– 2 theta: 50°22′
– Density: 7.09 g/cm^3
– Melting Point: 1750°C
– Mohs Hardness: 7.5 (Mohs)
– Refractive Index: 1.95
– Dielectric Constant: 30
– Growth Method: CZ

Standard Specifications:
– Orientation:
(100) miscut < 0.3° (Available <0.1°)
(110) miscut < 0.3° (Available <0.1°)
(111) miscut < 0.3° (Available <0.1°)
– Edge orientation: Available
– Dimensions: 5 x 5 x 0.5mm, 10 x 10 x 0.5 mm, dia 2 inch x 0.5 mm (Only for 111 orientation products)
– Surface Finish: Single-Side Polished / Double-Side Polished
– Surface Roughness: Ra: < 0.5 nm
